Fibreglass grp tubes - polyester matrix

Standard Profiles - Glass & Carbon Fibre

Glass Fibre Tubes - Polyester Matrix

fibreglass GRP tubes







APPLICATIONS
GRP light architecture
GRP tent poles

RBJ fibreglass tubes are pultruded with a high volume fraction of fibreglass in a polyester matrix to BS EN 13706 specifications.

We manufacture a wide range of unidirectional GRP tubes from 4mm up to 25mm in diameter.  Unidirectional fibreglass tubes have a smooth surface finish and are designed to give ultimate resistance to bending.  For GRP tubes 22mm or greater in diameter the fibreglass layup is a combination of multi-layered cross-ply fabrics, giving greater hoop strength that is resistant to bending and torsional forces.

GRP tubes are typically stocked in 5 metre lengths.  Unidirectional small GRP tubes are available in white or black.  Larger cross-directional GRP tubes are typically grey or white, other colours are available upon request.*

Optional matrices in vinyl ester and acrylic are also available upon request.*

As a UK manufacturer and pultrusion company we are able to tailor production and adapt to individual customer requirements.  Please call us to discuss.

*Minimum order required.

Dark grey rows - Non stock items, minimum order requirement

Note: All dimensions are nominal sizes (die sizes)

UNIDIRECTIONAL UPTO 31.8MM
O.D. I.D. kg/m
5.5 mm 3.2mm (1/8") 0.029
6 mm 3.2 mm (1/8") 0.030
6.0 mm 4.0 mm 0.031
6.35 mm (1/4") 3.2 mm (1/8") 0.043
8 mm 3.2 mm (1/8") 0.076
8.0 mm 4.7 mm (3/16") 0.063
8.0 mm 4.8 mm 0.063
8.0 mm 5.5 mm 0.048
9.5 mm (3/8") 6.35 mm (1/4") 0.080
10.0 mm 3.2 mm (1/8") 0.127
10.0 mm 5.0 mm 0.109
10.0 mm VINYLESTER 6.0 mm 0.104
10.0 mm 6.35 mm (1/4") 0.082
12.0 mm 7.5 mm 0.125
12.0 mm VINYLESTER 8.0 mm 0.121
12.7 mm (1/2") 6.35 mm (1/4") 0.164
12.7 mm (1/2") 8.5 mm 0.139
13.0 mm 9.5 mm (3/8") 0.122
14.0 mm VINYLESTER 11.0 mm 0.131
16.2 mm (5/8") 8.0 mm 0.262
16.2 mm (5/8") 12.2 mm 0.136
16.2 mm (5/8") 12.7mm (1/2") 0.130
19 mm (3/4") 10.0 mm 0.335
19 mm (3/4") 12.7 mm (1/2") 0.266
20.6 mm (13/16") 14.29 (9/16") 0.340
20.6 mm (13/16") 16.2 mm 0.195
22.2 mm(7/8") 16.6 mm 0.294
25.4 mm (1") 19 mm (3/4") 0.445
25.4 mm(1") 20.6 mm (13/16") 0.370
25.4 mm(1") 22.2 mm (7/8") 0.215
30 mm 26.0 mm 0.336
31.8 mm(1 1/4") 25.7 mm 0.460

CROSSDIRECTIONAL OVER 31.8MM

32.4 mm 26.0 mm 0.265
32.4 mm 28.3 mm 0.265
38.1 mm(1 1/2") 33.1 mm 0.480
41.0 mm 36.0 mm 0.490
44 mm(1 3/4") 38.7 mm 0.500
51 mm(2") 45.0 mm 0.666
60.0 mm 54.0 mm 0.975
82.0 mm 76.0 mm 1.200
110.0 mm 102.0 mm 2.150
152.0 mm 144.0 mm 3.600
31.8 mm(1 1/4") 25.4 mm  Ladder Rung 0.527
